At IWM, we utilize certified materials with known raw material origins. Our controlled processes and quality control maintain traceability of our material lots for our drawn wire, woven wire mesh, and post fabrication processes to ensure consistent quality performance for our customers’ products. IWM ensures best value to our customers through strategic sourcing of our raw materials through our worldwide supplier base.
Below you can find the typical specifications for our standard materials used for our aluminum, copper, commercial bronze, low carbon steel, and stainless steel products for your design considerations. However, for more specific details concerning chemistry, physical & mechanical properties, and finishes of our products, we encourage you to contact IWM for design assistance.
Aluminum
IWM offers fine wire and woven wire mesh products produced from a variety of aluminum alloys. IWM offers aluminum products for US Government and military applications requiring compliance to DFARS 252.225-7008 & -7009 concerning acquisition of Specialty Metals. IWM is in continuous production of fine wire and woven wire mesh products utilizing 5154A aluminum alloy. 5154A typical chemistry and properties are offered below:
| Alloy: | 5154A | Standard: | ASTM B211 | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Chemistry: | |||||||||
| AL | CR | CU | FE | Mg | Mn | Si | Ti | Zn | Residuals |
| 94.4 - 96.8% |
0.15 - 0.35% |
0.1% Max |
0.4% Max |
3.1 - 3.9% |
0.1% | 0.25% | 0.2% | 0.2% | < 0.15% |
| Physical Properties: | |||||||||
| Density: | 266g/cm3 or 166lb/ft3 |
Electrical Conductivity: | 32% IAC | ||||||
| Young Modulous: | 69 GPa or 10Msi |
Thermal Conductivity: | 130 W/m-K | ||||||
| Ultimate Tensile: | 230-330 mPa 33 to 48KSI | Thermal Expansion: | 23.9 µm/m-K | ||||||
| Finishes & Treatments: | |||||||||
| Fine Wire | Woven Wire Mesh | ||||||||
| Cold Drawn or Annealed. For further information concerning our fine wire finishes and treatments, click above. | Annealed, Cleaned Only, Varnished, Electro-Deposit Painting, Epoxy or Polyester Powder Coated. For further information concerning our woven wire mesh finishes & treatments, click above. | ||||||||
| Alloy: | 5154A | Standard: | ASTM B211 | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Chemistry: | |||||||||
| AL | CR | CU | FE | Mg | |||||
| 94.4 - 96.8% |
0.15 - 0.35% |
0.1% Max |
0.4% Max |
3.1 - 3.9% |
|||||
| Mn | Si | Ti | Zn | Residuals | |||||
| 0.1% | 0.25% | 0.2% | 0.2% | < 0.15% | |||||
| Physical Properties: | |||||||||
| Density: | 266g/cm3 or 166lb/ft3 |
Electrical Conductivity: | 32% IAC | ||||||
| Young Modulous: | 69 GPa or 10Msi |
Thermal Conductivity: | 130 W/m-K | ||||||
| Ultimate Tensile: | 230-330 mPa 33 to 48KSI | Thermal Expansion: | 23.9 µm/m-K | ||||||
| Finishes & Treatments: | |||||||||
| Fine Wire | |||||||||
| Cold Drawn or Annealed. For further information concerning our fine wire finishes and treatments, click above. |
|||||||||
| Woven Wire Mesh | |||||||||
| Annealed, Cleaned Only, Varnished, Electro-Deposit Painting, Epoxy or Polyester Powder Coated. For further information concerning our woven wire mesh finishes & treatments, click above. |
|||||||||
Copper & Copper Alloys
IWM offers fine wire and woven wire mesh products produced from a variety of copper and copper alloys. IWM offers products manufactured from annealed or soft Copper (99%+) per ASTM B3 standard for conductive applications such as electrical fine wire & ribbons and shielding applications for RFI, Faraday enclosures, and military TEMPEST protection. IWM offers C200 Brass alloy materials, as well. IWM is typically in production of Commercial Bronze (C220) for use as overbraid shielding for electrical cabling and hardware for marine and high corrosive applications. C220 chemistry and properties are offered below:
| Alloy: | C220 | Standard: | ASTM B36 | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Chemistry: | Cu | Zn | Pb | Fe | Residuals | ||||
| 89.0 - 91.0% |
8.7 - 10.7% |
0.05% Max |
0.05% Max |
<0.2% | |||||
| Physical Properties: | |||||||||
| Density: @68 °F | 8.80g/cm3 0.318lb/in3 |
Electrical Conductivity: | 44% IAC | ||||||
| Modulous of Elasticity: | 117kN/mm2 17,000KSI |
Thermal Conductivity: | 189W/m-K | ||||||
| Tensile Strength: (Annealed, Soft) |
250-290 MPa 36 to 42KSI |
Coeff. Thermal Expansion: | 18.36 PPM/°C 10.2 PPM/°F |
||||||
| Finishes & Treatments: | |||||||||
| Fine Wire | Woven Wire Mesh | ||||||||
| Cold Drawn Hard, Partial or Fully Annealed. For further information concerning our fine wire finishes & treatments, click above. | Cleaned Only or Varnish Coated. For further information concerning our woven wire mesh finishes & treatments, click above. | ||||||||
| Alloy: | C220 | Standard: | ASTM B36 | |||
|---|---|---|---|---|---|---|
| Chemistry: | Cu | Zn | Pb | Fe | ||
| 89.0 - 91.0% |
8.7 - 10.7% |
0.05% Max |
0.05% Max |
|||
| Residuals | ||||||
| <0.2% | ||||||
| Physical Properties: | ||||||
| Density: @68 °F | 8.80g/cm3 0.318lb/in3 |
Electrical Conductivity: | 44% IAC | |||
| Modulous of Elasticity: | 117kN/mm2 17,000KSI |
Thermal Conductivity: | 189W/m-K | |||
| Tensile Strength: (Annealed, Soft) |
250-290 MPa 36 to 42KSI |
Coeff. Thermal Expansion: | 18.36 PPM/°C 10.2 PPM/°F |
|||
| Finishes & Treatments: | ||||||
| Fine Wire | ||||||
| Cold Drawn Hard, Partial or
Fully Annealed. For further information concerning our fine wire finishes & treatments, click above. |
||||||
| Woven Wire Mesh | ||||||
| Cleaned Only or Varnish
Coated. For further information concerning our woven wire mesh finishes & treatments, click above. |
||||||
Low Carbon Steel
IWM offers fine wire and woven wire mesh products fabricated from low carbon steels ideally suited for mechanical applications requiring clean, consistent processes such as packaging, structural reinforcement media, fastening hardware, and binding wire. IWM is in continuous production of fine wire and woven wire mesh products utilizing AISI 1005 – 1010. AISI 1005 typical chemistry and properties is offered below:
| Alloy: | 1005 | Standard: | AISI/SAE | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Chemistry: | Fe | Mn | C | S | P | ||||
| 99.5 - 100% |
0.35% | 0.06% | 0.05% | 0.04 | |||||
| Physical Properties: | |||||||||
| Density: | 7.872 g/cm3 0.2844 lb/in3 |
Electrical Resistivity: | 17.4 µohm-cm | ||||||
| Modulous of Elasticity: | 190-210 GPa 27,557 – 30,458 KSI |
Bulk Modulus: (Typical) | 140 GPa 20,300 KSI |
||||||
| Shear Modulus: (Typical) | 80 GPa 11,600 KSI |
Coeff. Thermal Expansion: (@0-100°C) |
12.6 µm/m°C 7µin/in°F |
||||||
| Finishes & Treatments: | |||||||||
| Fine Wire | Woven Wire Mesh | ||||||||
| Cold Drawn, Annealed, Galvanized, Copper Coated. For further information concerning our fine wire finishes & treatments, click above. | Annealed, Galvanized, Electro-Deposit Painting, Epoxy or Polyester Powder Coated. For further information concerning our woven wire mesh finishes & treatments, click above. | ||||||||
| Alloy: | 1005 | Standard: | AISI/SAE | |||
|---|---|---|---|---|---|---|
| Chemistry: | Fe | Mn | ||||
| 99.5 - 100% |
0.35% | |||||
| C | S | P | ||||
| 0.06% | 0.05% | 0.04 | ||||
| Physical Properties: | ||||||
| Density: | 7.872 g/cm3 0.2844 lb/in3 |
Electrical Resistivity: | 17.4 µohm-cm | |||
| Modulous of Elasticity: | 190-210 GPa 27,557 – 30,458 KSI |
Bulk Modulus: (Typical) | 140 GPa 20,300 KSI |
|||
| Shear Modulus: (Typical) | 80 GPa 11,600 KSI |
Coeff. Thermal Expansion: (@0-100°C) |
12.6 µm/m°C 7µin/in°F |
|||
| Finishes & Treatments: | ||||||
| Fine Wire | ||||||
| Cold Drawn,
Annealed, Galvanized, Copper Coated. For further information concerning our fine wire finishes & treatments, click above. |
||||||
| Woven Wire Mesh | ||||||
| Annealed,
Galvanized, Electro-Deposit Painting, Epoxy or Polyester Powder Coated. For further information concerning our woven wire mesh finishes & treatments, click above. |
||||||
Stainless Steel
IWM offers woven wire mesh products fabricated from stainless steel. Stainless steel is typically selected for applications where corrosion resistance is required in a wide range of environmental conditions. Typical stainless mesh materials include 17-7 PH® (UNS S17700), 316 (UNS S31600), and 304 (UNS S30400). 17-7PH is typically utilized for applications requiring excellent fatigue properties such as in pressurize vessels and aircraft components. 316 is ideal for resistance to corrosion or pitting in marine or chloride salt environments. By far, 304 stainless is the most used stainless for most corrosion resistant applications and most readily available. 304 Stainless chemical and physical properties are listed below.
| Alloy: | UNS S30400 | Standard: | AMS 5513 | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Chemistry: | |||||||||
| C | Mn | P | S | Si | Cr | Ni | Cu | Mo | Fe |
| 0.08% Max |
2.00% Max |
0.04% Max |
0.03% Max |
1.00% Max |
18.00 - 20.00% |
8.00 - 10.00% |
0.75% Max |
0.75% Max |
Balance |
| Physical Properties: | |||||||||
| Density: | 8.03g/cm3 or 0.29lb/in3 | Electrical Resistivity: @20°C | 72 µohm-cm | ||||||
| Modulous of Elasticity: | 193 GPa or 28Msi (in tension) |
Thermal Conductivity: @ 100°C | 16.2 W/m-K | ||||||
| Ultimate Tensile (annealed) |
520 MPa 75 KSI |
Mean Coefficient of Thermal Expansion: (0-100°C) | 16.9 m/m-K | ||||||
| Finishes & Treatments: | |||||||||
| Fine Wire | Woven Wire Mesh | ||||||||
| Cold Drawn or Annealed. For further information concerning our fine wire finishes & treatments, click above. | Annealed, Epoxy or Polyester Powder Coated. For further information concerning our woven wire mesh finishes & treatments, click above. | ||||||||
| Alloy: | UNS S30400 | Standard: | AMS 5513 |
|---|---|---|---|
| Chemistry: | |||
| C | Mn | P | S |
| 0.08% Max |
2.00% Max |
0.04% Max |
0.03% Max |
| Si | Cr | Ni | |
| 1.00% Max |
18.00 - 20.00% |
8.00
- 10.00% |
|
| Cu | Mo | Fe | |
| 0.75% Max |
0.75% Max |
Balance | |
| Physical Properties: | |||
| Density: | 8.03g/cm3 or 0.29lb/in3 | Electrical Resistivity: @20°C | 72 µohm-cm |
| Modulous of Elasticity: | 193 GPa or 28Msi (in tension) |
Thermal Conductivity: @ 100°C | 16.2 W/m-K |
| Ultimate Tensile (annealed) |
520 MPa 75 KSI |
Mean Coefficient of Thermal Expansion: (0-100°C) | 16.9 m/m-K |
| Finishes & Treatments: | |||
| Fine Wire | |||
| Cold Drawn or
Annealed. For further information concerning our fine wire finishes & treatments, click above. |
|||
| Woven Wire Mesh | |||
| Annealed, Epoxy
or Polyester
Powder Coated. For further information concerning our woven wire mesh finishes & treatments, click above. |
|||
